Architectural Ceiling Series
High-Performance WPC Baffle Ceilings: Sculpting Modern Interiors
Transform your ceiling into a design statement with premium suspended WPC tubes. Lightweight, fire-retardant, and easy-to-install timber tube systems designed for airports, malls, and corporate hubs.
Rapid Lock System
B1 Fire Rated
E0 Eco-Safety
FAST
Lock-in
Carrier System
Carrier System
Linear Fluidity: The Open-Cell Advantage
Yuheng International’s WPC Baffle Ceiling system is an engineered “open-cell” architectural solution designed to add rhythmic depth to interior overhead spaces. Composed of high-precision suspended WPC tubes, this system creates a warm, timber-like aesthetic without the weight or flammability of natural wood.
Unlike traditional gypsum or metal ceilings, the baffle system allows for a transparent visual flow, effectively concealing technical utilities (HVAC, fire sprinklers, cabling) while maintaining complete accessibility for maintenance. The linear profiles also provide a natural acoustic diffusion effect, significantly softening sound reverb in high-traffic commercial environments.
Visual Extension
Enhance room length or width through linear perspective.
Utility Accessibility
Easy access to services without removing panels.
Weather Integrity
Moisture-proof core ideal for semi-outdoor spaces.
Rapid Lock-in
Tool-free carrier system for high-speed install.
Profile Portfolio: Engineering Your Ceiling
Select the ideal cross-section to control the rhythmic density and visual depth of your overhead architecture.
The Standard Rectangular
The most versatile profile for creating a classic timber-slat effect. High aspect ratio for dramatic perspective lines.
Section Size: 40x60mm / 50x100mm
Wall Thickness: 1.0mm – 2.0mm
The Geometric Square
Perfect for creating minimalist, matrix-style grids or alternating patterns for contemporary office hubs.
Section Size: 50x50mm / 75x75mm
Wall Thickness: 1.2mm – 1.8mm
The Custom Large Span
Reinforced heavy-duty profiles designed for massive public infrastructure projects with wide joist spans.
Section Size: 100x150mm / Custom
Wall Thickness: Up to 3.0mm
Bespoke Profile Development
Require a specific geometry for a global commercial tender? Our engineering team supports custom die-casting and specialized length extrusions (up to 6m).
Why Spec Yuheng WPC Ceilings?
Engineering peak performance where aesthetics meet building safety compliance.
Class B1 Fire Rated
Compliant with international commercial building codes. Our material is self-extinguishing for maximum public safety in high-occupancy zones.
Lightweight Structural Safety
Significantly lighter than aluminum or solid timber. Reduces building dead-load and simplifies the overhead suspension engineering.
Zero Humidity Warping
100% moisture resistant. Perfect for humid tropical climates, lobbies with high-traffic temperature fluctuations, and coastal infrastructures.
E0 Eco-Safety Certified
Zero formaldehyde emissions. Ensures clean indoor air quality, making it ideal for schools, hospitals, and modern corporate headquarters.
Technical Specifications
Precision-engineered profiles designed for professional architectural assembly and heavy-duty ceiling spans.
Core Composition
Reinforced WPC Matrix
High-density composite of bamboo wood fiber and pure resins, ensuring zero sagging over long spans.
Architectural Finish Layer
Advanced hot-melt lamination or transfer printing for hyper-realistic timber textures and anti-UV stability.
Internal Cavity
Hollow-core design for weight reduction and thermal insulation, compatible with internal steel reinforcement.
Dimension & Dimensional Stability
| Standard Sections | 40x60mm / 50x100mm / 25x80mm |
| Wall Thickness | 1.0mm – 3.0mm (Project Optimized) |
| Standard Length | 3.0m, 4.0m, 6.0m (Customizable) |
| Density | 1.3g/cm³ – 1.4g/cm³ |
Industrial Performance Standards
| Fire Resistance | Class B1 (EN 13501-1) |
| Formaldehyde Release | E0 Grade (≤ 0.5 mg/L) |
| Moisture Absorption | < 0.8% (24-hour immersion) |
| Certification Compliance | CE, SGS, FSC, ISO9001 |
Suspension System: The “Fast-Lock” Carrier
Our WPC Baffle Ceiling is engineered as a complete modular system. The core of its efficiency lies in the specialized Fast-Lock metal carrier, which facilitates rapid alignment and securement without the need for individual tube fastening.
01
Main Carrier Mounting
Heavy-duty galvanized steel carriers are suspended from the structural slab using adjustable threaded rods. This creates the primary horizontal datum for the ceiling.
02
Tool-Free Tube Snap-In
WPC tubes are simply pushed upward into the pre-punched tabs of the carrier. The “Lock-in” mechanism ensures each baffle is perfectly vertical and aligned automatically.
03
Seamless Utility Integration
The vertical gaps between baffles allow for integrated lighting tracks, fire sprinklers, and HVAC diffusers to be installed while keeping the main service lines completely hidden.
System Flexibility
- Adjustable Baffle Spacing (Standard 50mm – 200mm)
- Compatible with Linear LED Lighting Channels
- High Vertical Load Bearing Capacity
- Easy Disassembly for Utility Maintenance
- Custom Carrier Punching for Rhythmic Design
Engineer’s Pro-Tip
For high-traffic public areas like airport terminals, we recommend our “Anti-Wind” carrier series which features secondary locking clips to prevent baffle vibration from air pressure changes.
Strategic Application Scenarios
Transforming commercial overheads into rhythmic design assets across major industrial sectors.
Public Infrastructure
Transit Hubs & Terminals
Ideal for airports and railway stations. The suspended WPC tube system provides the necessary Class B1 fire safety while creating long, flowing perspective lines that guide passenger movement.
Commercial & Retail
Retail Malls & Plazas
Enhance the premium feel of commercial atriums. Our baffle ceilings offer high visual impact and conceal heavy HVAC systems without blocking airflow or acoustic performance.
Corporate Hubs
Modern Office Interiors
Define breakout zones and open-plan workspaces. The timber-like texture adds warmth to professional environments, and the open structure integrates seamlessly with modern fire safety and lighting grids.
Hospitality
Hotel Lobbies & Lounges
Create a grand entrance with natural wood aesthetics. Our moisture-proof core ensures the ceiling retains its perfectly straight profile even in high-humidity luxury hotel environments.
B2B Wholesale & Project Supply
Strategically empowering global architectural firms and distributors with factory-direct timber tube ceiling solutions.
Global Hub Logistics
Located in Linyi, China’s core timber logistics center, we specialize in the safe and cost-effective shipping of ultra-long profiles (3m – 6m), ensuring lower freight costs for bulk B2B orders.
Technical OEM Support
Need a custom sectional profile or a proprietary color for a massive infrastructure tender? Our engineering team provides custom die development and technical prototyping for project-specific needs.
Architectural Consistency
We guarantee batch-to-batch color stability and dimensional precision. Our ceiling profiles are engineered to perfectly sync with Yuheng WPC wall panels for a holistic interior finish.
Ceiling System FAQ
Technical insights and planning guidance for modern WPC baffle installations.
Absolutely. The open gaps between the WPC tubes are ideal for standard 50mm-100mm wide linear LED channels. We can also provide customized metal carriers with pre-engineered wider slots to accommodate specialized lighting tracks, ensuring a perfectly flush architectural finish.
Our WPC tubes feature an internal reinforced matrix that resists sagging. For ultra-long commercial spans (over 4m), we provide specialized internal steel reinforcement sleeves. Combined with our high-precision metal carrier system, the tubes are locked into a fixed horizontal plane, preventing visual “bowing” or misalignment.
Yes. As a B2B project supplier, we provide “Ready-to-Install” kits which include the WPC profiles, specialized galvanized steel carriers, L-angle wall trims, and even the necessary suspension clips. This one-stop supply model ensures 100% mechanical compatibility and reduces onsite procurement delays.
The spacing is determined by the punching intervals on the metal carrier. While 50mm and 100mm are our most common standard spacings, we can custom-punch the carriers to any required interval (e.g., 75mm or 150mm) for large projects to achieve your specific vision of visual transparency or sound diffusion.
WPC Baffle Ceilings provide excellent acoustic diffusion. The linear tubes break up sound waves and prevent “flutter echoes” common in large halls with hard floors. While the system is open, it can be combined with acoustic insulation pads placed above the baffles to achieve superior sound absorption (high NRC ratings) without sacrificing the architectural aesthetic.
Our WPC Baffle system is Class B1 Fire Rated according to international standards (EN 13501-1 / GB/T 8624). This means the material is “Difficult to Ignite” and self-extinguishes upon removal of the flame source. We provide full third-party laboratory test reports with every bulk order to assist with building code compliance and fire marshal approvals.
Elevate Your Commercial Overhead with Yuheng
Partner with China’s leading factory for premium WPC Baffle Ceiling systems. Our engineering team is ready to support your next project with specialized technical consultations and factory-direct wholesale pricing.
24-Hour Inquiry Response & Quote Guarantee
Specialized Packaging for 3m – 6m Ultra-Long Profiles
Free Technical CAD & Suspension Layout Support
CE Certified
B1 Fire Rated
Global Logistics
